Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable

Name: Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable
Brand: Huaxin or OEM
Price: 0.35 USD

Brand Name : Huaxin or OEM

Model Number : Outdoor Fiber Optic CableGYTA

Certification : CE, ISO9001

Place of Origin : China

MOQ : 2000M

Price : $0.35

Payment Terms : L/C,T/T

Supply Ability : 500km PER DAY

Delivery Time : 7-14work days

Packaging Details : 1000-2000km per tray, according to customer's requirement Plastic tray or wooden tray. Plastic or pearl cotton outer cover, suitable for ocean transportation

Contact Now

Outdoor Stranded Loose Tube Light Armored Cable GYTA Optical Fiber Cable

GYTA is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply GYTA fiber optic cable from 2 fiber cores to 12 fiber cores. Both single mode type and multimode types are available.The fibers, 260μm, are positioned in a loose tube made of a high modulus plastic.The tubes are filled with a water-resistant filling compound.The tube is wrapped with a layer of corrugated steel tape longitudinally.Between the corrugated steel tape and the loose tube water-blocking material is applied to keep the cable compact and watertight.Two parallel steel wires are placed at the two sides of the steel tape.The cable is completed with PE sheath.

Feature 6 core fiber optic cable

Low dispersion and attenuation Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties.6 core fiber optic cable The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance.6 core fiber optic cable Operating Temperature : -40~+60 ℃

Cable Parameters
Items		Specifications
Fiber Count		2~24
Colored Coating Fiber	Dimension	260µm±15µm
Colored Coating Fiber	Color	Blue, Orange, Green, Brown, Gray, White
Loose Tube Dimension 2.10mm±0.05mm	Dimension	2.10mm±0.05mm
	Material	PBT
	Color	Natural
Strength Member	Diameter	1.0mm
Strength Member	Material	Steel
Outer Jacket	Dimension	8.0mm±0.1mm
	Material	PE
	Color	Black

Technical Parameter
Fiber Count	Cable Diameter (mm)	Cable Weight (kg/km)	Tensile Strength Long/Short Term (N)	Crush Resistance Long/Short Term (N/100mm)	Bending Radius Static/Dynamic (mm)
2~12	10.6	124	1000/3000	1000/3000	10D/20D
14~24	12.0	147	1000/3000	1000/3000	10D/20D

Lead time

Quantity (meters)	1 - 2000	2001 - 10000	> 10000
Lead time (days)	7	14	To be negotiated

Packing and Transportation

Cable in stock, ship same day.

1 or 2km for a wooden roll.

One roll packed with carton.

Other length is also avaiable without MOQ.

Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable

Factory & Production

Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable

Certifications

Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable

Exhibitions

Stranded Loose Tube Light Outdoor Armored Fiber Optic Cable GYTA Optical Fiber Cable

FAQ
1. Are you real manufacturer?
Yes, our factory is located in Shandong, China.
2. Can you provide the samples?
Yes, Samples free of charge, but freight necessary to bear yourself.
3. What is the delivery time?
It takes 3-5 days for the samples, 7-15 days for the bulk production. It depends on the order quantity.
4. Can you supply customized products and logo? (OEM/ODM)
Yes, we can provide the OEM/ODM, please feel free to let us know your requirements.
5.Do you have warranty for your products?
Yes,-There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands
